Specification

mode of operation : Non-maintained with 150 Vac line under-voltage detection

Input voltage : 220 Vac ± 150% / 50 Hz

Control system : Microcontroller-based control system with solid-state SMART-CHARGER

Battery type : Sealed lead-acid battery (ISO 9001 , ISO 14001 , CE , and UL certified)

Battery charging method : Two-steps constant coltage and two-steps current limits with SMART-CHARGER

Batter cut-off voltage : 10.5 V ± 2%

Maximum charging current : 700 mA

Charging time : 10 - 16 hrs

Lamps : LM-80 certified high-lumen LEDs with metal-core PCB and aluminum heat-sink ofr excellent heat management

Beam contril : high effciency PMMA lenses with rated beam angle 36º

Color temperature : 3000 4500 K, CRI > 70 (daylight option also available)

LED driver : Constant current

Brightness : Constant brightness with 4 levels programmable dimming for extended backup times

Manual test : 90-min test by either pushing Multi-Function button or using remote control

Auto Test : 90-min test every 4 weeks (Enable/Disable selectable)

Remote* : IR remote contril for ON, OFF, Test, Dim and Auto Test Enable/Disable functions

Standards : TIS 1955-2551 , TIS 1102-2538 , ISO 9001

Casing : 1.7-mm-thick extruded aluminum coated with poeder paint
